Horizontal Bandsaws

Large Red Horizontal Bandsaw in Storage Area

Vectrax Horizontal Bandsaw

About our machine

• Large Red Horizontal Bandsaw (Storage Area)
  • Maker: Southern Tool and Equipment of TR
  • Blade Size: 116" x 3/4" 5-10 tpi
• Vectrax 7-inch Metal Cutting Bandsaw
  • Maker: Vectrax
  • Model: 712G
  • Blade Size: 93" x 3/4"
  • Cutting Capacity: 7" x 12"

Guides and Manuals

• [ Large Red Horizontal Bandsaw] - none available
• Vectrax Horizontal Bandsaw

Vetrax Horizontal Bandsaw Do’s and Don’ts

Do

• Use this machine only if you have been trained in its correct use.
• Always run saw at the slowest speed when cutting any steel alloy.
• Always check any steel alloy with a file before cutting to make sure it has not been heat treated higher than 28-32 Rockwell C. (Example: If you can file it and make chips, it can be cut in the saw.)
• If using saw at middle or high-speed range (plastics, aluminum, brass, copper, etc.), return it to slow speed when done.
• Use cutting oil or WD-40 when cutting aluminum to prevent material from galling on blade.
• When cutting a heavy cross section of material, allow 3-5 teeth to engage in work before releasing arm.
• When cutting material with varying thickness of cross sections (I Beam, Channel Iron, Structural Tubing), use hydraulic down feed control to limit the down feed rate.

Don't

• Never attempt to cut thin wall pipe or tubing. Use a hacksaw or abrasive saw.

Maintenance

Parts:
